Johnson/Evinrude outboard parts drawings *How to videos

T.C. Electroninics/Marine (Please click here for home page)

Evinrude/Johnson outboard powerhead gasket kit

GLM aftermarket OMC powerhead gasket sets
Rebuild kit for years 1972 and up

Click on photo for exploded view



Price
(US $)

Price
(Canadian $)

39353 9hp-15hp years 1993 thru 1999

39353 9hp-15hp years 1993 thru 1999

P/N 39353 2 Cylinder $38.99
9.9 and 15 hp. Years 1993 to 2011

$50.99

39380 9.9 -15 hp. 1984 thru 1992 powerhead gasket set
39380 9.9 -15 hp. 1984 thru 1992 powerhead gasket set
P/N 39380 2 Cylinder 9.9 and 15 hp. 1974 to 1992 $33.99

$43.99

39420 Powerhead gasket set
39420 Powerhead gasket set
P/N 39420 2 Cylinder $66.99
20, 25, 28, 30 hp. 1979 up
35 hp. 1979 to 1986

$86.99

39370 power head gasket
39370 power head gasket

P/N 39370 2 Cylinder $108.99
40, 45, 48 and 55 hp. Years 1980 to
50 hp. years 1971, 1972, 1973, 1974 and 1975
55 hp. year 1976
55 hp. years 1977, 1978 and 1979
50 hp. year 1980
55, 60 hp. years 1980, 1981, 1982, 1983, 1984 and 1985
Photos of all parts included

$141.99

39355 40 hp commercial crossflow outboard
P/N 39355 2 Cylinder $36.99
40 hp. Commercial Years 1983, 1984, 1985 and 1986

$47.99

39390 3 cylinder 50-60-65-70 hp OEM-438904
P/N 39390 3 Cylinder $57.99
50 hp. year 1995
60 hp. 1989 - up
65 hp. 1987 - up
70 hp. 1986 - up
Head gasket is included in set

$75.99

39350 gasket set

39350 gasket set

P/N 39350 $99.99
60 hp. years 1986, 1987 and 1988
65 hp. use P/N 33400 head gasket plus 1972 to 1973
65 hp. 1984, 1985 and 1986
70 hp. 1974 to 1985

$129.99

39360 Powerhead gasket set 2

39360 Powerhead gasket set 2

P/N 39360 V- 4 Cross $113.99
85 hp. 1973 to 1977
115, 135 and 140 hp. use 33540 head gasket plus P/N 39360 for years 1973 to 1977

$147.99

39080 Powerhead gasket set 2

39080 Powerhead gasket set 2

P/N 39080 V 4 Cross $127.99
85, 88, 90, 110 and 115 hp. 1979 to
100, 115 and 140 hp. 1978 to 1984
115 hp. year 1985

$166.99

39400 90 degree V4 loopcharged 120-140 hp powerhead gasket kit
39400 90 degree V4 loopcharged 120-140 hp powerhead gasket kit
P/N 39400 V-4 Loopcharged 90 degree $82.99

120, 140 hp. years 1988 to 1994
130 hp. year 1995

$107.99

39354 V4 loopcharge 120-140 hp 1985-1986-1987
39354 V4 loopcharge 120-140 hp 1985-1986-1987
P/N 39354 V- 4 Loopcharged 90 degree $99.99
 120, 140 hp. years 1985, 1986 and 1987

$129.99

39351 2 V4 loopcharged carb 1995 up 90-115hp
39351 2 V4 loopcharged carb 1995 up 90-115hp
P/N 39351 V 4 Loopcharged 60 degree $162.99
90 hp. to 115 Years 1995 up

$211.99

39356 V4 loopcharged EFI 90hp-115hp 1998 up
39356 V4 loopcharged EFI 90hp-115hp 1998 up
P/N 39356 V- 4 Loopcharged with FFI $69.99

$77.99

39090
39090

P/N 39090 V-6 Cross 90 degree $135.99
150 hp. 1978 to 1991
155 hp. 1986 to 1991
175 hp. 1977 to 1985
185 hp. 1984 and 1985
200 hp. 1976 to 1983
235 hp. 1978 and 1979

$176.99

39430 V6 Crossflow 90 degree 175 hp 1986 thru 1991
39430 V6 Crossflow 90 degree 175 hp 1986 thru 1991
P/N 39430 V- 6 Crossflow 90 degree $80.99
175 hp. 1986 to 1991
235 hp. 1980 to 1985

$105.99

39070 1994-1998 V8 250-275-300 special
39070 1994-1998 V8 250-275-300 special
P/N 39070 V-8 $244.99
275 hp. and 3.6 liter years 1985 to 1993 OEM only
200 and 250 FFI year 2001 OEM only
250, 275 and 300 hp. Special years 1988 up

$317.99

39352 V6 loopcharged carburetor
39352 V6 loopcharged carburetor
P/N 39352 V 6 Loopcharged OEM 6039352 $166.99
150-175 V6 1991 to 1999

$216.99

39930 V6 loopcharged carb
39930 V6 loopcharged carb
P/N 39930 V-6 Loopcharged 90 degree power head gasket kit $104.95
200, 225 hp. 1985, 1986 and 1987

$136.99

39410 V6 Loopcharged 90-200-225 hp 1988 thru 1993
39410 V6 Loopcharged 90-200-225 hp 1988 thru 1993
P/N 39410 V-6 Loopcharged 90 degree $94.99
200, 225 hp. 1988 to 1993

$123.99

39510 V6 loopcharged 200hp 225hp 250hp 1994-2001
39510 V6 loopcharged 200hp 225hp 250hp 1994-2001

P/N 39510 $155.95

$232.99
