Take the boat to OMC outdrives Johnson outboard
Mercruiser listing for bell housing complete with tech support drawings
  • Bell Housing Alpha One or Mercruiser parts
  • Transom service kit for R, MR and Alpha One stern drive
  • Bell housing drawing with bellows parts and component photo
  • Mercruiser parts kit includes the following:
  • 89050 U-Joint Bellow OEM # 60932A4
  • 89100 Exhaust Bellow OEM # 18654A1
  • 89080 Shift Cable Bellow OEM # 74639
  • 39622 Gasket Kit OEM # 27-94996T2
  • 21900 Gimbal Bearing OEM # 30-60794A4
  • 47110 Water Hose 3/4" OEM # 32-41725-33
  • 47120 Water Hose 5/8 " OEM # 32-32461
  • Bellows cross reference chart  with model number, model year and serial number for exhaust, shift cable and u-joint bellows

Aftermarket Mercruiser parts
89100 Mercruiser Exhaust Bellows.jpg
Exhaust bellow # 89100

#89100 $28.98

OEM #18654A1

For units with exhaust bellow 1973 thru 1990
#21950 Mercruiser outdrives and Alpha One outdrives serial #6225577 thru transom service kit

#21950 $134.98



Mercruiser sterndrives
Alpha One outdrives , Alpha One Gen.II gasket kit #39622

#39622 $6.98


Aftermarket U-joint bellow
89050 U-Joint Bellow.jpg
U-joint bellow OEM # 60932A4 # 89050

#89050   $47.98



Serial #6225577 thru Mercruiser-Alpha One drives
#21951 For units 1983 thru 1990 with straight exhaust bellow

#21951   $157.98



120/ 140/ 160/ 165 1967 to72 & 888 Series 1971-72
89200 U-Joint Bellow
#89040 U-joint bellow with clamps Serial #2062141 thru 3443920 & 888 Serial 106717 to 3472477

#89040   $53.98



OEM# 36223A2
Water hose .750 Mercruiser sterndrives
Water hose 3 / 4

#47110 $8.98



Use wuth all Mercruiser or Alpha One outdrives.
21900 Gimbal bearing.jpg
# 21900 Gimbal bearing OEM # 983937

#21900 $41.98
