Evinrude / Johnson V4 90 degree small gearcase identification for lower unit years 1978 thru 1998
  • Physical characteristics 18 3/16 inches tall with 4-1/8 inch hub
  • Straight at the trailing end of the gear housing and the fin
  • Pointed at the trailing end of the cavitation plate
  • Six holes above the cavitation plate and 7-1/4 inch from plate to centre of prop shaft
  • Internal water intake screens (four holes) and no pitot

Click on illustration below for tech drawing

Click here Exploded view lower unit parts drawing
V4 90 degree small gearcase identification years 1978 thru 1998
