Johnson outboard ignition coils
Horsepower and year
Outboard motor ignition coils
72010 Johnson outboard coil
# 72010 Aftermarket Johnson outboard motor ignition coils

# 72010 $19.98 SOLD OUT

OEM #582508
4 hp. Deluxe 1985 thru
4.5 hp. 1986 thru 1987
5 hp. 1985 thru 1991
6 hp. 1985 thru 1990
6.5 hp. Commercial 1989 thru 1990
8 hp. 1985 thru 1990
9.9, 15 hp. 1985 thru
20 hp. 1985 thru
25 hp. 1985 thru
25 hp. Commercial 1985 thru 1991
28 hp. 1989 thru
30 hp. 1985 thru
40 hp. 1985 thru 1988
40 hp. Commercial 1985 thru 1990
40 Commercial 1985 thru 1992
45 SS.hp.1987 thru 1990
48 hp. 1987 thru
50 hp. 1985 thru 1988
60 hp. 1985 thru
60 SST.hp.1989 thru 1990
65 hp.Commercial 1985 thru
70 hp. 1985 thru
75 hp. 1985 thru
85 hp. 1985 thru
88 hp. 1987 thru
90 hp. 1985 thru 1994
100 hp. 1985 thru
1600 CC 1988
110 hp. 1986 thru 1990
120 hp. 1987 thru
125 hp. 1991 thru
125 hp. Comm.1989 thru
140 hp. 1985 thru
150 (A) hp. 1985 thru A = will not fit loopers
155 hp. Comm.1984 thru 2500 CC 1988
175 (A) hp. 1985 thru A = will not fit loopers
185 hp. 1984 thru
200 hp. 1985 thru
225 hp 1986 thru
250 hp. 1991 thru
275 hp. 1985 thru
300, 3.6 1985 thru
Sail drive 1985 thru
# 72030 Johnson ignition coils
72030 johnson parts coil
# 72030 Aftermarket Johnson Ignition Coils
OEM # 502881

# 72030 $28.98 SOLD OUT


18,20 hp. 1973
25 hp. 1973 thru 1976
35 hp. 1976
40 (B) hp.1975 thru 1983 B is contact controlled engines
72040 Johnson Outboard Coil
# 72040 Johnson ignition coils (Aftermarket OMC Parts)
OEM #502888

# 72040 $27.98

85 hp. 1976 thru 1977
115 hp. 1976 thru 1977
135 hp. 1976
135 hp. 1977
150 hp. 1976 thru 1978
175 hp. 1976 thru 1978
200 hp. 1976 thru 1978
235 hp 1976 thru 1978
Coils for Johnson / Evinrude Outboards
72050 Johnson Outboards Coil
# 72050 Johnson Outboards Coils
OEM #502890

# 72050 $27.98 SOLD

50 hp. 1971 thru 1975
65 hp. 1971 thru 1975
70 hp. 1974 thru 1975
70 hp. 1974 thru 1974
85 hp. 1973 thru 1975
115 hp. 1973 thru 1974
135 hp. 1973 thru 1975
#72080 outboard motor ignition coil
Ignition coil #72080 for use with Johnson outboard parts
OEM # 502888

#72080 $21.98

4 hp. 1977 thru 1980
4.5 hp. 1980 thru 1984
6 hp. 1977 thru 1984
7.5 hp. 1980 thru 1984
8 hp. 1980 thru 1984
9.9, 15 hp.1977 thru 1984
9.9, 15hp. 4-Stroke 1994 thru
10,14 hp. Commercial 1989 thru 1990
25 hp. 1974 thru 1984
28 hp. 1987 thru 1988
30 hp. 1977 thru 1984
35 hp. 1977 thru 1984
40 hp. 1977 thru 1984
50 hp. 1978 thru 1984
55 hp. 1978 thru 1984
60 hp. 1978 thru 1984
65 hp. 1979 thru 1984
75 hp. 1979 thru 1984
85 hp. 1978 thru 1984
90 hp. 1978 thru 1984
100 hp. 1978 thru 1984
115 hp. 1978 thru 1994
140 hp. 1978 thru 1984
150 hp. 1979 thru 1984
175 hp. 1979 thru 1984
200 hp. 1979 thru 1984
235 hp. 1979 thru 1984
sail drive 1985 thru
