Yamaha outboard head gaskets 2-250 hp. V4-V6 motors

GLM marine aftermarket head gaskets

Exploded view Yamaha lower unit drawings
Search by part number or description here

34900 Head gasket

34900 Head gasket

P/N 34900 2 hp.
OEM 6A1-11181-00 $10.00


9.9 hp. (4 stroke) years 1985 to 1990

P/N 018-38270 $45.00

33890 9.9 15 hp. outboard
33890 9.9 15 hp. outboard
9.9 / 15 hp. years 1988 to 1993

P/N 33890 OEM 6E7-11181-00 $12.00

33880

33880

25 hp. two cylinder years 1984 to 1987
30 hp. years 1984 to 1986
C30 hp. years 1989 to 1992

P/N 33880 Head gasket OEM 6E7-11181-00 $24.00


25 hp. two cylinder years 1988 to 1993

P/N 018-38470 $48.00

Sierra 018-38490 Mariner
Sierra 018-38490 Mariner

C25 hp. years 1990 to 1993
CV25 hp. year 1990

P/N 018-38490 $27.29

34920 30 hp. years 1987 - 1997
34920 30 hp. 1987 - 1997

30 hp. years 1987 to 1997

P/N 34920 head gasket #6J8-11181-A1-00 $16.00

34930
34930

CV 30 hp. Year 1989
40 hp. years 1984 to 1993
50 hp. years 1984 to 1993
Pro 50 hp. years 1988 to 1993

P/N 34930 #6H4-11181-A1-00 $27.00



C40 hp. two cylinder years 1990 to 1997
CV40 hp. year 1990

# 018-38920 $54.00



C 55 hp. years 1989 to 1991
CV 55 hp. year 1989

# 018-38480 $39.00

34940 Yamaha
34940 Yamaha

P60 hp. year 1991
70 hp. 3 Cylinder 1984 to 1991

P/N 34940 Head gasket OEM 6H3-11181-A1 $30.00

34950
34950

C 85 hp. years 1989 to 1991
CV 85 hp. years 1989 to 1993
90 hp. years 1984 to 1993

P/N 34950 Head gasket 688-11181-A0 $31.00

34960
34960

115 hp. (6E5) year 1984
115 hp. years 1986 to 1999
115 hp. (6N6) years 1992 to 1997
C115 hp. years 1991 to 1995
P115 hp. years 1993 to 1996
L130 hp. (6L6) 130 hp. (6L1) years 1988 to 1991
L130 hp. (6N4) 130 hp. (6N7) years 1994 to 1999

P/N 34960 Head gasket #6E5-11181-A1 $27.00

P/N 018-38320 Sierra $45.00



C150 hp. years 1996 to 1999
L150 hp. years 1986 to 1989
P150 hp. years 1986 to 1995
150/175/200 hp. ETLN/ETXN years 1984 to 1989
150/L150/P150/PRO V150D years 1990 to 1995
175 hp. (6R3) 1990 to 1994
P175 hp (62H) year 1994
P200 hp. (61H) years 1991 to 1994
L200 hp. (6R4) 200 hp. (6R1) years 1991 to 1995
V6 Special (6G7) years 1984 to 1986
V6 Excel (6K7) years 1987 to 1989
225 hp. 2.6 Litre Eng years 1990 to 1995

# 018-38940 $55.00



225 hp. / L 225 hp. 3.1 Litre Eng years 1994 to 1996
250 hp. / L 250 hp. years 1990 to 1996

# 018-38910 $75.00

34910 8 hp 2 cylinder
34910 8 hp. 2 cylinder
P/N 34910 Head gasket OEM 677-11181-00 $16.00
