Evinrude/Johnson outboard parts drawing
Type "O" V4 and V6 large gearcase lower unit
Identification for years 1979 thru 2006
  • Physical characteristics 19 3/16 inches tall with 4-5/8 inch rear hub
  • Straight at the trailing end of the gear housing and the fin
  • Pointed at the trailing end of the cavitation plate
  • Two slots above the cavitation plate with 8-1/4 inches betten plate and centre of prop shaft and external water intake screens
Click here Johnson outboard parts exploded drawing
Type O V4-V6 large gearcase years 1979 thru 2006
