Your on-line distributor for GLM aftermarket Evinrude / Johnson outboard motor power pack replacement units

Aftermarket power packs and amplifiers for 2 Cyl. thru 6 Cyl. Evinrude / Johnson outboard motors. OMC power pack terminal identification for Evinrude / Johnson outboard power packs as follows:

# 1 Charge coil/brown
# 2 Ignition coil # 1 / orange
# 3 Ignition coil # 2 / orange
# 4 Ground lead / black
# 5 Key switch / black-yellow
# 6 Sensor / white-black
# 7 sensor black-white
# 8 Vacant

Johnson outboard power pack
# 75370 Johnson outboard power pack

OEM # 581397

50 hp. 1971 thru 1975
55 hp. 1976 thru 1977

#75370  $79.96

NO LONGER AVAILABLE


Johnson / evinrude power pack
# 75340 Johnson / evinrude outboard motor power pack

OEM # 581731

  85 hp.1973 thru 1977
115 hp.1973 thru 1977
135 hp.1973 thru 1976
140 hp.1977

#75340  $98.96

NO LONGER AVAILABLE

OEM # 582056

Same as #75340 or OEM # 581731
but without hardware pack

  85 hp.1973 thru 1977
115 hp.1973 thru 1977
135 hp.1973 thru 1976
140 hp.1977

#75350  $90.96

NO LONGER AVAILABLE

OEM # 582125

Note 2 required per engine

  85 hp. 1978 thru 1980
  90 hp. 1981 thru 1983
100 hp. 1979 thru 1980
115 hp. 1978 thru 1983
140 hp. 1978 thru 1983

#75380  $69.96

NO LONGER AVAILABLE

Johnson outboard power pack unit
# 75380 Johnson power pack unit

OEM # 581726

  65 hp. 1972 thru 1973
  70 hp. 1974 thru 1978
  75 hp. 1975 thru 1978
175 hp. 1977 thru 1978
200 hp. 1976 thru 1978
235 hp. 1978

#75330        $94.96

NO LONGER AVAILABLE

OEM # 582057

Same as #75330 / OEM #581726 without hardware

  65 hp. 1972 thru 1973
  70 hp. 1974 thru 1978
  75 hp. 1975 thru 1978
175 hp. 1977 thru 1978
200 hp. 1976 thru 1978
235 hp. 1978

#75360  $85.96

NO LONGER AVAILABLE

OEM # 582556
OEM # 582642
OEM # 582400
OEM # 582138

2 Required per outboard motor

70,75 hp. 1979 thru 1984
150 hp. 1979 thru 1984
*Port side only for 1983 model # STLCT
175 hp. 1979 thru 1983
185 hp. 1984
200 hp. 1979 thru 1983
235 hp. 1979 thru 1984
*Port side only for 1983 model # STLCT
*Port side only for 1984 model with suffix beginning with " S "

#75390  $84.96

NO LONGER AVAILABLE

Johnson / Evinrude outboard power pack unit
# 75390 Johnson outboard power pack unit

OEM # 583380
OEM # 582453

   4 hp. 1977 thru 1980 and 1984
4.5 hp.1980 thru 1984
   5 hp. 1984
   6 hp. 1977 thru 1979 and 1984
7.5 hp.1980 thru 1983
9.9,15 hp. 1977 thru 1984
  20 hp. 1981 thru 1984
25 hp. 1977 thru 1984
Note 25 hp. All models above except 1983 Comm. for year 1983
30 hp. 1984
35 hp. 1977 thru 1984
40 hp. 1982
50 hp. 1979,1981 thru 1984

#75400  $55.96

NO LONGER AVAILABLE

Johnson / Evinrude outboard power pack unit
# 75400 Johnson power pack unit
